PGA-IVM Series
Best in Class Valves with Preinstalled IVM-SOL
Rain Bird PGA Series valves are now available with the Integrated Valve Module "smart solenoid" (IVM-SOL) preinstalled. The new IVM Smart Valves, when paired with the ESP-LXIVM Two-Wire controller, eliminate decoders resulting in 50% fewer wire splices, which reduces system cost and improves reliability. During operation, the IVM-SOL provides two-way communication between the valve and controller to provide advanced diagnostic capability and faster response time.
SUGGESTED PRODUCT
Features
Best-in-Class Valves
With industry-leading reliability and performance, the Rain Bird PGA Series of commercial valves are now even better with preinstalled IVM-SOL
Next Generation Two-Wire System
The ESP-LXIVM Two-Wire Controller is the next leap forward—simplifying installation, improving reliability and enabling more troubleshooting features that save time
Performance and Reliability
With 50% fewer connections, an IVM Smart Valve is already 200% more reliable out of the box versus using a valve and decoder
Features
Globe and angle configuration for flexibility in design and installation
PVC and glass reinforced nylon construction
Filtered pilot flow to resist debris and clogging of solenoid ports
Slow closing to prevent water hammer and subsequent system damage
Manual internal bleed operates the valve without allowing water into the valve box
One-piece solenoid design with captured plunger and spring for easy servicing prevents loss of parts during field service
Non-rising flow control handle adjusts water flows as needed
Normally closed, forward flow design
Options (order separately)
Accommodates optional, field installed PRS-D pressure regulating module
Specs
Accommodates optional, field installed PRS-D pressure regulating module
Flow: 2 –150 gpm (0.45 to 34.05 m3/h; 7.8 to 568 l/m)
Flow with PRS-D: 5 –150 gpm (1.14 to 34.05 m3/h; 19.2 to 568 l/m)
Water Temperature: up to 110° F (43° C)
Ambient Temperature: up to 125° F (52° C)
Electrical Specifications
Power: 26.5 Vrms 50/60 Hz (cycles/sec)
Inrush current: <40mA (Peak)
Quiescent current: <0.4mA (ave.)
Voltage range: 15.6 - 29.2 Vrms
Compatible with LXIVM controllers
Dimensions (H x W x L)
IVM100PGA: 7.25” (18.4 cm), 5.5” (14.0 cm), 3.25” (8.3 cm)
IVM150PGA: 8” (20.3 cm), 6.75” (17.2 cm), 3.5” (8.9 cm)
IVM150PGA: 10” (25.4 cm), 7.75” (19.7 cm), 5” (12.7 cm)
Model Comparison
Model
- IVM100PGA: 1" Valve with IVM-SOL
- IVM150PGA: 1.5" Valve with IVM-SOL
- IVM200PGA: 2" Valve with IVM-SOL
