PE-IVM Series
Best in Class Valves with Preinstalled IVM-SOL
Rain Bird PGA and PEB/PESB Series valves are now available with the Integrated Valve Module "smart solenoid" (IVM-SOL) preinstalled. The new IVM Smart Valves, when paired with the ESP-LXIVM Two-Wire controller, eliminate decoders resulting in 50% fewer wire splices, which reduces system cost and improves reliability. During operation, the IVM-SOL provides two-way communication between the valve and controller to provide advanced diagnostic capability and faster response time.
SUGGESTED PRODUCT
Features
Best-in-Class Valves
With industry-leading reliability and performance, the Rain Bird PEB/PESB Series of commercial valves are now even better with preinstalled IVM-SOL
Next Generation Two-Wire System
The ESP-LXIVM Two-Wire Controller is the next leap forward—simplifying installation, improving reliability and enabling more troubleshooting features that save time
Performance and Reliability
With 50% fewer connections, an IVM Smart Valve is already 200% more reliable out of the box versus using a valve and decoder
Features
Body constructed of durable glass-filled nylon for long life and heavy-duty performance at 200 psi (13.80 bar) pressure
Stainless steel studs molded into the body. Bonnet can be attached and removed more easily without damaging threads
One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service
External bleed protects the solenoid ports from debris when system is flushed
Internal bleed operates the valve without allowing water into the valve box; allows pressure regulator to be adjusted without turning on the valve at the controller first
Low flow operating capability (0.25 gpm; 0.06 m3/h; 1.2 l/m) for a wide range of applications. For flows below 5 gpm (1.14 m3⁄h; 19.2 l/m) or any Xerigation® application, install Rain Bird Y filter upstream
Slow closing to prevent water hammer and subsequent system damage
PESBIVM only: Scrubber scrapes its stainless steel screen clean to break down grit and plant material. Prevents debris build-up and clogging
Options (order separately)
Accommodates optional, field installed PRS-D pressure regulating module to ensure optimum sprinkler performance
Optional purple flow control handles for non-potable water applications: PEB-NP-HAN1(1”) & PEB-NP-HAN2 (11⁄2” and 2”)
Specs
Pressure: 20 to 200 psi (1.38 to 13.80 bar)
Flow: 0.25 to 200 gpm (0.06 to 45.40 m3⁄h; 1.2 to 757 l/m)
Flow with PRS-D: 5 to 200 gpm
(1.14 to 45.40 m3⁄h; 19.2 to 757 l/m)
Temperature: up to 150° F (66° C)
Electrical Specifications
Power: 26.5 Vrms 50/60 Hz (cycles/sec)
Inrush current: <40mA (Peak)
Quiescent current: <0.4mA (ave.)
Voltage Range: 15.6 - 29.2 Vrms
Compatible with LXIVM controllers
Dimensions (H x L x W)
100 - 6.5” (16.5 cm), 4” (10.2 cm), 4” (10.2 cm)
150 - 8” (20.3 cm), 6” (15.2 cm), 6” (15.2 cm)
200 - 8” (20.3 cm), 6” (15.2 cm), 6” (15.2 cm)
Model Comparison
Model
- 100PEBIVM & 100PESBIVM: 1" Valve with IVM-SOL
- 150PEBIVM & 150PESBIVM: 1.5" Valve with IVM-SOL
- 200PEBIVM & 200PESBIVM: 2" Valve with IVM-SOL
