Rain Bird detail drawings for Sports Field Irrigation products are now available in two popular formats: DWG for AutoCAD users, and PDF for easy viewing and printing.

To download a file, just right-click on the link and select "Save Target As..." from the menu. For your convenience, drawings are available for individual download or grouped into a self-extracting compressed archive that contains all drawings.

Download zipped archive of all Sports Fields CAD Drawings (DWG & PDF formats) (ZIP: 15.6 MB)

Tennis Design Plans

Minimum GPM Minimum
PSI
DWG Format PDF
Tennis, grass or clay, 6504 rotor 47 65 DWG PDF
Tennis, grass or clay, 6504 high speed rotor 63 65 DWG PDF
Tennis, grass or clay, 6504 rotor 53 85 DWG PDF
Tennis, clay, 6504 high speed rotor 69 75 DWG PDF
Tennis, grass or clay, 8005 rotor 48 75 DWG PDF
