IMR Series Specialty Media

Iron and Manganese Removal

Rain Bird IMR-Series Specialty Media is a revolutionary silica sand based filtration media designed for the removal of iron and manganese without the use of potassium permanganate. The unique micro porous structure of the IMR-Series efficiently removes dissolved iron to as low as 0.005 ppm and manganese to 0.001 ppm. After initial activation, the IMR-Series acts as an oxidation catalyst with immediate oxidation and filtration of the insoluble precipitates. The media has been used extensively in a wide variety of applications for over 30 years. The IMR-Series has been tested and certified by the Water Quality Association in accordance with NSF/ANSI 61.



  • Eliminates Potassium Permanganate. Operates with continuous injection of sodium hypochlorite at low residual levels (0.1 to 0.3 ppm).
  • Wide pH range. Stable and satisfactory performance at pH 5.8 to 8.6.
  • High Flow Rates. The IMR-Series can operate at linear filtration velocities up to twice that of conventional media with a corresponding reduction in capital equipment costs.
  • Higher Operating Temperatures. Maximum operating temperature of 113° F (45° C).
  • Long Life. The IMR-Series is not consumed in the process, providing considerable advantages over other processes or media.
  • Regeneration Not Required. After initial activation, only sodium hypochlorite feed is required.
  • System Compatibility. Physical properties are similar to that of competitive media, allowing conversion to the IMR-Series without major hardware modifications.
  • Arsenic Removal. The IMR-Series has been shown to be effective in the removal of arsenic associated with iron-containing influent. If necessary, ferric chloride can be introduced to treat waters with low influent iron levels or to enhance removal when treating waters with high levels of arsenic.
